Based on the regular 1000/750/500*250*45mm panels, 1250*250*45mm not only could be used to replace the combination of 750/500*250*45mm panels, but also realizes more flexible & highly efficient installation and save more cost and labor.
The mural series is an upgraded version, specially designed for indoor fixed installation. The whole panel is direct-mounted onto the structure without disassembling any accessories.
A: To choose the right pixel pitch for the LED screen, we must consider the environment used, the viewing distance, and the size of the screen. In indoor fashion stores, supermarkets, restaurants, scenic spots and museums, etc., we can choose LED indoor products with small dot pitch, such as P1.5, P1.9, P2.6 P3.9. Mainly used for long-distance applications that disseminate information, we recommend P10-P20, such as stadiums and shopping malls.The smaller the pixel pitch, the finer the picture. We have professional solutions for your different project needs and application ranges.
A: When designing the screen size, there are important factors:
The need to display content
Site space conditions
Display cell template size or pixel size
Power Consumption and Power Requirements
A: For example, Mural series is an upgraded version, specially, desiged fo indoor fixed installation. The whole panel is direct-mounted onto the structure without disassembling any accessories. Fix the bracket or mounting joint on the mounting surface. Splice the cabinets together into one row. Connect the cables and then mount thecabinets onto the bracket by mounting joint. Install the cabinets row by row onto the structure from the bottom.
Mark the hole positions of the frame according to cabinet& screen size, drill holes and install screws.
Put the frame onto the wall with expansion screws.
Put empty cabinets onto the frame with specific screws.
Connect power and signal cables between cabinets, and assemble modules onto cabinets, all modules should be placed upward.
Connect the main power and signal cables of the whole screen.
Ledtop's main Commercial LED Display include Dragon series and Goku pro. Dragon's mechanized design gives customers better operation experience. Dragon series have high contrast ratio, grey scale 16bit/18bit , the brightnees decreases and the gray level remains, high refreshrate from3840HZ to 7680HZ. Goku pro is new Die-casting cabinet. Goku pro and Mural are more used in commercial fixed indoor display, because they provides energy saving to our customers.
